HP A5120 EI Series User Manual

109
127.0.0.0/8 127.0.0.1 U InLoop0 Null Invalid
127.0.0.1/32 127.0.0.1 UH InLoop0 Null Invalid
# Display FIB information passing ACL 2000.
<Sysname> system-view
[Sysname] acl number 2000
[Sysname-acl-basic-2000] rule permit source 10.2.0.0 0.0.255.255
[Sysname-acl-basic-2000] display fib acl 2000
Destination count: 2 FIB entry count: 2
Flag:
U:Useable G:Gateway H:Host B:Blackhole D:Dynamic S:Static
R:Relay
Destination/Mask Nexthop Flag OutInterface InnerLabel Token
10.2.0.0/16 10.2.1.1 U Vlan1 Null Invalid
10.2.1.1/32 127.0.0.1 UH InLoop0 Null Invalid
# Display all entries that contain the string 127 and start from the first one.
<Sysname> display fib | begin 127
Flag:
U:Useable G:Gateway H:Host B:Blackhole D:Dynamic S:Static
R:Relay
Destination/Mask Nexthop Flag OutInterface InnerLabel Token
10.2.1.1/32 127.0.0.1 UH InLoop0 Null Invalid
127.0.0.0/8 127.0.0.1 U InLoop0 Null Invalid
127.0.0.1/32 127.0.0.1 UH InLoop0 Null Invalid
# Display FIB information passing the IP prefix list abc0.
<Sysname> system-view
[Sysname] ip ip-prefix abc0 permit 10.2.0.0 16
[Sysname] display fib ip-prefix abc0
Destination count: 1 FIB entry count: 1
Flag:
U:Useable G:Gateway H:Host B:Blackhole D:Dynamic S:Static
R:Relay
Destination/Mask Nexthop Flag OutInterface InnerLabel Token
10.2.0.0/16 10.2.1.1 U Vlan1 Null Invalid
Table 25 Output description
Field
Description
Destination count
Total number of destination addresses
FIB entry count
Total number of FIB entries
Destination/Mask
Destination address/length of mask
Nexthop
Next hop address
