Table 33 I/O card events that might illuminate SID LEDs (continued)
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
SFWI/O SBA clear error
failed
Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED
I/O Card
SFWPCI-X slot power on errorType E0h, 146d:26dI/O Card
IO_SLOT_POWER_ON_ERROR
SFWPCI-X slot has incorrect
default power state
Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR
I/O Card
SFWI/O host bridge (Lower
Bus Adapter) is
Type E0h, 136d:26d
IO_LBA_RESET_ERROR
I/O Card
inaccessible because
rope reset failed to
complete
SFWPCI clock DLL errorType E0h, 130d:26dI/O Card
IO_DLL_ERROR
SFWI/O rope reset failed to
complete
Type E0h, 143d:26d
IO_ROPE_RESET_ERROR
I/O Card
SFWPCIe link failed to trainType E0h, 7346dI/O Card
CC_IODISC_LBA_LINK_TRAIN_ERR
SFWPCIe link is not running
at maximum capable
bandwidth
Type E0h, 7356d
IO_PCIE_LINK_SUBOPTIMAL
I/O Card
Troubleshooting the iLO 3 subsystem
This subsection provides information on troubleshooting issues with the iLO 3 subsystem.
iLO 3 MP LAN LED on the rear panel
The iLO 3 MP LAN supports two LEDs, viewable from the rear of the system:
• iLO 3 LAN link LED, which indicates link speed
• iLO 3 LAN activity, which indicates link activity
Table 34 iLO 3 MP LAN Activity LED states
LED stateLink status
Flashing greenActivity
Steady greenLink with no activity
OffNo link
NOTE: For information on the LAN LED, see “System LAN LEDs” (page 88).
Troubleshooting the I/O subsystem
This subsection provides information on troubleshooting issues with the I/O subsystem.
Verifying SAS hard drive operation
Each SAS disk drive has an activity LED indicator on the front of the drive.
Troubleshooting the iLO 3 subsystem 87
