7 Removal and replacement procedures
IMPORTANT: Replacing the fans and power supplies
If a cooling fan or power supply fails, you must replace it. Replacement usually takes no longer
than 5 minutes. For instructions on replacing these components, see “Removing and replacing a
hot-swap fan” (page 101) and “Removing and replacing a hot-swap power supply” (page 98).
Server components list
IMPORTANT: Part numbers are found by using the part nomenclature from this list to select the
correct part from HP Partsurfer (http://www.partsurfer.hp.com/search.aspx).
To select a replacement part from the full component list, enter the product number for your system.
Table 37 CRU list
Spare part numberDescription
Processors
AH339-6914AIntel Itanium 1.6-GHz Dual-core processor 10-MB cache
AH339-6915AIntel Itanium 1.46-GHz Quad-core processor 16-MB cache
Intel Itanium 1.6-GHz Quad-core processor 20-MB cache
AH395-67004Replacement, Processor heat sink
1
Memory (DIMMs)
AM326-69001DDR3 Memory Module 2 GB
AM327-69001DDR3 Memory Module 4 GB
AM328-69001DDR3 Memory Module 8 GB
AM363-69001DDR3 Memory Module 16 GB
Power supply
451816-001-48VDC Hot Plug Power Supply
Internal disks and removable media
512743-00172-GB/15K 2.5" SAS hard disk drive
507283-001146-GB/10K 2.5" SAS hard disk drive
512744-001146-GB/15K 2.5" SAS hard disk drive
507284-001300-GB/10K 2.5" SAS hard disk drive
581310-001450-GB/10k 2.5" SAS 6Gb Hard Disk Drive
581311-001600-GB/10k 2.5" SAS 6Gb Hard Disk Drive
AM242-6700AHP DVD ROM slimline
AM243-6700AHP DVD+RW slimline
Risers
496057-001PCIe IO Riser, 3 PCI-Express slots; 1 x8, 2 x4
AH395-69002PCA, Memory Riser
Boards
