9. Tie wrap the processor cable to the right tie point on the processor assembly.
CAUTION: When the processor is installed, dress all slack in the power cable to the connector
end of the cable. Failure to do so can result in pinched or damaged processor power cables.
NOTE: If you are adding an additional processor to your server, the DIMMs in the server must
be reconfigured to support both processors. For more information, see “Memory configurations”
(page 47).
HP Trusted Platform Module (TPM)
The TPM is not a customer-serviceable part.
CAUTION: Any attempt to remove an installed TPM from the system board breaks or disfigures
the TPM security rivet. Upon locating a broken or disfigured rivet on an installed TPM, administrators
should consider the system compromised and take appropriate measures to ensure the integrity of
the system data.
If you suspect a TPM board failure, leave the TPM installed and remove the system board (“Removing
and replacing the system board” (page 119)). Contact an HP authorized service provider for a
replacement system board and TPM board.
Verifying installed components in the server
Use the following procedure to verify that the components you have installed into the server are
recognized by the server:
1. Press S to enter the UEFI shell.
2. Wait for the UEFI Shell prompt to appear.
56 Optional components
