Table 3-4 Computer Setup—Security (continued)
Option Description
USB Security Allows you to disable individual or groups (Front, Rear, and Accessory) of USB ports.
NOTE: The media card reader is connected to the Accessory port.
Slot Security Allows you to disable the PCIe slot along with the card plugged into it.
Network Service Boot Enables/disables the computer’s ability to boot from an operating system installed on a network
server. (Feature available on NIC models only; the network controller must be either a PCI
expansion card or embedded on the system board.)
System IDs Allows you to set:
●
Asset tag (18-byte identifier), a property identification number assigned by the company to
the computer.
●
Ownership tag (80-byte identifier) displayed during POST.
●
Chassis serial number or Universal Unique Identifier (UUID) number. The UUID can only be
updated if the current chassis serial number is invalid. (These ID numbers are normally set in
the factory and are used to uniquely identify the system.)
●
Keyboard locale setting (for example, English or German) for System ID entry.
DriveLock Security Allows you to assign or modify a master or user password for hard drives. When this feature is
enabled, the user is prompted to provide one of the DriveLock passwords during POST. If neither
is successfully entered, the hard drive will remain inaccessible until one of the passwords is
successfully provided during a subsequent cold-boot sequence.
NOTE: This selection will only appear when at least one drive that supports the DriveLock
feature is attached to the system. You may need to power-cycle the system and re-enter F10
Setup in order to manage DriveLock passwords.
See the Desktop Management Guide for more information.
14 Chapter 3 Computer Setup (F10) Utility
