Changing from Desktop to Tower Configuration
1. Prepare the computer for disassembly (Preparation for Disassembly on page 31).
2. Place the computer firmly down into the stand.
Figure 6-41 Placing the Computer on the Stand
3. Reconnect the external equipment, plug the power cord into a power outlet, and turn the
computer on.
4. Lock any security devices that were disengaged when the computer cover or access panel was
removed.
To change from the tower configuration to the desktop configuration, reverse the previous steps.
NOTE: An optional Quick Release mounting bracket is available from HP for mounting the computer
to a wall, desk, or swing arm.
Power Supply, External
The USDT chassis uses an external power supply.
WARNING! To reduce potential safety issues, only the power supply provided with the computer, a
replacement power supply provided by HP, or a power supply purchased as an accessory from HP
should be used with the computer.
70 Chapter 6 Removal and Replacement Procedures
