Interpreting POST Diagnostic Front Panel LEDs and
Audible Codes
This section covers the front panel LED codes as well as the audible codes that may occur before or
during POST that do not necessarily have an error code or text message associated with them.
WARNING! When the computer is plugged into an AC power source, voltage is always applied to
the system board. To reduce the risk of personal injury from electrical shock and/or hot surfaces, be
sure to disconnect the power cord from the wall outlet and allow the internal system components to
cool before touching.
NOTE: If you see flashing LEDs on a PS/2 keyboard, look for flashing LEDs on the front panel of
the computer and refer to the following table to determine the front panel LED codes.
Recommended actions in the following table are listed in the order in which they should be
performed.
Not all diagnostic lights and audible codes are available on all models.
Table F-2 Diagnostic Front Panel LEDs and Audible Codes
Activity Beeps Possible Cause Recommended Action
Green Power LED On. None Computer on. None
Green Power LED flashes
every two seconds.
None Computer in Suspend to
RAM mode (some models
only) or normal Suspend
mode.
None required. Press any key or move the
mouse to wake the computer.
Red Power LED flashes two
times, once every second,
followed by a two second
pause. Beeps stop after fifth
iteration but LEDs continue
until problem is solved.
2 Thermal protection
activated:
Air flow is restricted, a fan
may not be functioning, or
the heatsink is not
properly attached.
1. Clean the air vents on the front, back, or
any other vented side of the computer.
2. Ensure that there is a 10.2 cm (4 in)
clearance on all vented sides of the
computer to permit the required airflow.
3. Ensure that computers are not stacked on
top of each other or so near each other that
they are subject to each other's re-
circulated or preheated air.
4. If the computer is within an enclosure,
ensure that there is proper intake and
exhaust ventilation for the enclosure.
5. If a message appears on the screen
indicating that a fan is not working, replace
the fan.
6. Ensure that the heat sink is properly
attached.
132 Appendix F POST Error Messages

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
