HP Compaq 6005 Pro

Monitor
Connector and Icon
Pin Signal Pin Signal
1
2
3
4
Red Analog
Green Analog
Blue Analog
Not used
9
10
11
12
+5V (fused)
Ground
Not used
DDC Serial Data
5
6
7
8
Ground
Ground
Ground
Ground
13
14
15
Horizontal Sync
Vertical Sync
DDC Serial Clock
DisplayPort
Connector and Icon
TOP ROW BOTTOM ROW
Pin Signal Type Pin Name Pin Signal Type Pin Name
74 Appendix A Connector Pin Assignments
