HP Compaq 6005 Pro User Manual

Cable Management
Always follow good cable management practices when working inside the computer.
●
Keep cables away from major heat sources like the heat sink.
●
Do not jam cables on top of expansion cards or memory modules. Printed circuit cards like these
are not designed to take excessive pressure on them.
●
Keep cables clear of sliding or moveable parts to prevent their being cut or crimped when the
parts are moved.
●
Do not bend any cable sharply. A sharp bend can break the internal wires.
●
Never bend a SATA data cable tighter than a 30 mm (1.18 in) radius.
●
Never crease a SATA data cable.
●
Do not rely on components like the drive cage, power supply, or computer cover to push cables
down into the chassis. Always position the cables to lay properly by themselves.
System board connectors are color-coded to make it easier to find the proper connection.
Connector Name Connector Color Description
CHFAN_FRONT Maroon Front chassis fan
CHFAN_REAR Maroon Rear chassis fan
SPKR White Internal speaker
SATA0 Black Hard drive data and power
SATA1 White Optical drive data
SATA PWR White Optical drive power
HSENSE White Hood sensor
MEDIA Black Card reader
Cable Management
47

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
