Replacing the Optical Drive
The Ultra-Slim Desktop uses a slimline Serial ATA (SATA) optical drive.
Removing the Existing Optical Drive
1. Prepare the computer for disassembly (Preparation for Disassembly on page 31).
2. If the computer is on a stand, remove the computer from the stand and lay the computer down.
3. Remove the computer access panel (
Computer Access Panel on page 40).
4. Disconnect the cable on the rear of the optical drive (1), push the green release latch on the right
rear side of the drive toward the center of the drive (2), then slide the drive forward and out of
the bay through the front bezel (3).
Figure 6-19 Removing the Optical Drive
48 Chapter 6 Removal and Replacement Procedures
