HP Compaq NC4000 User Manual

13–8 Hardware and Software Guide
Computer Setup
Device options ■ Enable/disable multiple standard
pointing devices at startup. (To set
the notebook to support only a single,
usually nonstandard, pointing device at
startup, select Disable.)
■ Select a parallel port mode: EPP
(Enhanced Parallel Port), standard,
bidirectional, or ECP (Enhanced
Capabilities Port).
■ Enable/disable USB legacy support for a
USB keyboard, mouse, and hubs. When
USB legacy support is enabled:
❐ A USB keyboard, mouse, and hubs
work even when a Windows
operating system is not loaded.
❐ The notebook starts from a
bootable hard drive, diskette drive
diskette, or CD-R, CD-RW, or DVD
inserted into a drive connected by
a USB connector to the notebook
or to an optional docking device.
■ Swap the functions of the fn key and left
ctrl key.
■ Enable/disable LAN Power Save Mode.
■ Enable/disable the fan to always be
on while the notebook is connected to
AC power.
■ Enable/disable Intel® SpeedStep.
■ Enable/disable LAN/WLAN switching.
■ Enable/disable Bluetooth and WLAN.
✎
Bluetooth and WLAN settings are
accessible only if the notebook is
equipped with a Bluetooth or WLAN
device.
Select To Do This

HP Compaq NC4000 Specifications

General

Processor cache	1 MB
Processor model	-
Processor frequency	1.4 GHz
Processor cache type	L2
Processor front side bus	400 MHz
Processor core voltage (AC)	0.956 - 1.388 V
HDD speed	5400 RPM
HDD interface	Ultra-ATA/100
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	40 GB
Compatible memory cards	SD
Number of HDDs installed	1
Pixel pitch	0.264 x 0.264 mm
Display diagonal	12.1 \
Display brightness	130 cd/m²
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Display number of colors	16.78 million colors
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Power requirements	90 - 264V, 47/63Hz
Wireless technology	Wi-Fi
Graphics card family	AMD
Compatible operating systems	Windows XP
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	0.25 GB
Internal memory type	DDR-SDRAM
Maximum internal memory	1 GB
Audio system	PS
Pointing device	Touchpad
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows XP Professional
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	2
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Number of battery cells	6
Operating shock	40 G
Operating altitude	0 - 3048 m
Non-operating shock	240 G
Operating vibration	0.5 G
Non-operating altitude	0 - 9144 m
Non-operating vibration	1 G
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	UL, CSA, VDE/TUV
Product color	Black, Silver
Country of origin	China

Weight and Dimensions

Depth	233.7 mm
Width	279.4 mm
Height	27.9 mm
Weight	1590 g
