4–6 Hardware and Software Guide
Multimedia
Using the S-Video-Out Jack
To connect a video device to the S-Video-out jack:
1. Connect either end of an S-Video cable into the S-Video-out
jack on the notebook.
2. Connect the other end of the cable to the video device. Refer
to the video device documentation for more information.
✎
If the S-Video-out jack on the notebook is not accessible
because the notebook is docked into an optional docking
device, connect the device to the S-Video-out jack on the
docking device.
