2–12 Startup and Reference Guide—Part 2
Hardware
Right Side
Right Side
1
Antenna (available on select
models and not visible from
outside the notebook)
*
Sends and receives wireless device
signals.
2
Infrared port Provides wireless communication
between the notebook and an optional
IrDA-compliant device.
3
Power connector Connects an AC adapter cable.
4
Security cable slot Attaches an optional security cable to
the notebook.
*The notebook has 2 antennas. The second is on the right side of the
notebook. For optimal transmissions, keep the areas immediately over
the antennas free from obstructions.
CPQ-311245-001.book Page 12 Tuesday, April 1, 2003 3:55 PM
