2–14 Startup and Reference Guide—Part 2
Hardware
Docking Connector and Vents
Underside: Docking Connector and Vent
1
Docking connector* Connects the notebook to an optional
port replicator.
2
Vents (3) Allow airflow to cool internal
components.
Ä
To prevent overheating, use
the notebook only on hard
surfaces which cannot
obstruct the vents. Do not
allow a soft surface, such as
bedding, clothing or a thick
rug, to block airflow.
*As shipped, the docking connector is not visible. The docking connector is
beneath the docking connector cover, which protects the connector when
the connector is not in use.
