To remove a hard drive from and internal 3.5-inch drive bay, pull up on the green hard drive
drivelock mechanism (1) for that drive and slide the drive from the drive bay (2).
Figure 7-30 Removing a Hard Drive
5. Store the removed drive in anti-static packaging.
90 Chapter 7 Removal and Replacement Procedures Convertible Minitower (CMT) Chassis
