Front Bezel
1. Prepare the computer for disassembly (Preparation for Disassembly on page 63).
2. Remove the computer access panel (
Computer Access Panel on page 70).
3. Push up on the two release tabs (1), then rotate the front bezel away from the chassis to release
it (2).
Figure 7-9 Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
Front Bezel 71
