Bezel Blank
On some models, there is a bezel blank covering the external drive bay that needs to be removed before
installing a drive. To remove a bezel blank:
1. Remove the computer access panel (
Front Bezel on page 184).
2. Push the two retaining tabs that hold the bezel blank in place towards the outer right edge of the
bezel (1) and pull the bezel blank inwards to remove it (2).
Figure 9-11 Removing a Bezel Blank
Bezel Blank 185
