HP dc7900 - Convertible Minitower PC

9. Slide the cover on the carrier (1) and replace the screw on the rear of the carrier to secure the cover
in place (2).
Figure 8-54 Replacing the Carrier Cover
10. Slide the hard drive carrier into the enclosure on the computer and lock it with the key provided.
NOTE: The carrier must be locked for power to be supplied to the hard drive.
160 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
