7. Pull the power supply forward until the posts on the power supply move forward in the power supply
bracket, and then lift the power supply straight up and out of the chassis.
Figure 8-65 Removing the power supply
To install the power supply, reverse the removal procedure.
CAUTION: When installing the power supply cables, make sure they are properly positioned so they
are not cut by the drive cage and are not pinched by the rotating power supply.
170 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
