HP dc7900 - Convertible Minitower PC User Manual

4. Open both latches of the memory module socket (1), and insert the memory module into the
socket (2).
Figure 7-13 Installing a DIMM
NOTE: A memory module can be installed in only one way. Match the notch on the module with
the tab on the memory socket.
A DIMM must occupy the black DIMM1 socket.
For maximum performance, populate the sockets so that the memory capacity is spread as equally
as possible between Channel A and Channel B.
5. Push the module down into the socket, ensuring that the module is fully inserted and properly
seated. Make sure the latches are in the closed position (3).
6. Repeat steps 4 and 5 to install any additional modules.
7. Replace the computer access panel.
8. Reconnect the power cord and turn on the computer.
9. Lock any security devices that were disengaged when the computer access panel was removed.
The computer should automatically recognize the additional memory the next time you turn on the
computer.
78 Chapter 7 Removal and Replacement Procedures Convertible Minitower (CMT) Chassis

HP dc7900 - Convertible Minitower PC Specifications

General

Chipset	Intel Q45 Express
Memory	Up to 16 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Form Factor	Convertible Minitower
Processor	Intel Core 2 Duo, Core 2 Quad, Pentium Dual-Core
Storage	SATA Hard Drives
Graphics	Intel Graphics Media Accelerator 4500, optional discrete graphics
Optical Drive	DVD-ROM, DVD+/-RW
Network	Integrated Intel Gigabit Network Connection
Ports	USB 2.0, serial, parallel, audio in/out
Expansion Slots	PCI, PCIe x1, PCIe x16
Operating System	Windows Vista, Windows 7
