HP DL360 Reference And Troubleshooting Guide

60 HP ProLiant DL360 Generation 4 Server Reference and Troubleshooting Guide
5. Remove the expansion slot cover from the slot, if installed ("Installing an
Expansion Board" on page 58
).
6. Remove the expansion board from the slot, if installed ("Expansion Board"
on page 57
).
7. Remove the applicable PCI riser boards from the assembly:
IMPORTANT: When removing the two parts of the riser board, pay
attention to the orientation of the slots on each side. This information is
important for subsequent procedures.
a. Remove the riser board with the slot for full-length expansion boards.
b. Repeat the previous step for the riser board with the slot for half-length
expansion boards, if needed.

HP DL360 Specifications

General

Processor Sockets	2
CPU	Intel Xeon Scalable
Memory	Up to 3TB DDR4
Form Factor	1U Rack
Power Supply	Redundant Power Supplies, various wattage options
Network Controller	Embedded 1Gb or 10Gb Ethernet
RAID Support	Smart Array RAID
Operating System Support	Windows Server, Linux, VMware
Storage	Up to 10 SFF SAS/SATA/NVMe drives or 4 LFF SAS/SATA drives
