HP DL360 Reference And Troubleshooting Guide

63
Server Cabling
In This Section
Cabling Overview.........................................................................................................................63
Server Cable Routing....................................................................................................................63
SATA Cable Routing....................................................................................................................64
Cabling Overview
This section provides guidelines that help you make informed decisions about
cabling the server and hardware options to optimize performance.
For information on cabling peripheral components, refer to the white paper on
high-density deployment at the HP website
(http://www.hp.com/products/servers/platforms
).
Server Cable Routing
CAUTION: When routing cables, always be sure that the
cables are not in a position where they can be pinched or crimped.

HP DL360 Specifications

General

Processor Sockets	2
CPU	Intel Xeon Scalable
Memory	Up to 3TB DDR4
Form Factor	1U Rack
Power Supply	Redundant Power Supplies, various wattage options
Network Controller	Embedded 1Gb or 10Gb Ethernet
RAID Support	Smart Array RAID
Operating System Support	Windows Server, Linux, VMware
Storage	Up to 10 SFF SAS/SATA/NVMe drives or 4 LFF SAS/SATA drives
