62 HP ProLiant DL360 Generation 4 Server Reference and Troubleshooting Guide
a. Install the riser board with the slot for full-length boards onto the
assembly.
b. Repeat the previous step for the riser board with the slot for half-length
expansion boards, if needed.
10. Install the PCI Express expansion board ("Installing an Expansion Board" on
page 58
).
11. Install the PCI riser board assembly ("Installing PCI Riser Board Assembly"
on page 29
).
IMPORTANT: The server will not power up if the PCI riser board
assembly is not seated properly.
12. Connect any internal or external cabling to the expansion boards.
13. Install the access panel ("Installing the Access Panel" on page 28
).
