Item Component Spare part number
(1) Display panel (includes microphone assembly) L14784-001
(2) System board (includes processor, replacement thermal material, Mylar screw/POGO cover, bottom thermal Mylar, side
thermal Mylar, and thermal grease):
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Equipped with an Intel Core i5-7Y54 processor and 8 GB of system memory L14753-xx1
Equipped with an Intel Core i5-7Y54 processor and 4 GB of system memory L14752-xx1
Equipped with an Intel Core i5-7Y30 processor and 4 GB of system memory L14754-xx1
(3) WLAN Antenna Kit (includes main and aux antennas and cables, Mylar screw/POGO cover,
thermal shield bottom Mylar, thermal shield side Mylar (2), and thermal grease)
L14787-001
(4) WWAN Antenna Kit (includes antennas and cables, Mylar screw/POGO cover, thermal shield
bottom Mylar, thermal shield side Mylar (2), and thermal grease)
L14789-001
Cameras (include Mylar screw/POGO cover):
(5) Infrared camera L14772-001
(6) Front camera L14773-001
(7) Rear camera L14774-001
(8) Solid-state drive, M.2 (includes Mylar screw/POGO cover and WLAN RF foil):
256-GB, PCIe, NVMe L16843-001
128-GB, SATA-3, TLC L16842-001
Speakers (include Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and thermal grease)
(9) Left speaker:
●
For use in models without WWAN L14786-001
●
For use in models with WWAN (includes WWAN antenna) L14768-001
(10) Right speaker:
●
For use in models without WWAN L14785-001
●
For use in models with WWAN (includes WWAN antenna) L14767-001
(11) WWAN module, HP LT4210 LTE/HSPA+ with GPS (includes gasket and Mylar screw/POGO cover) L15398-005
(12) USB Type-C bracket, left (includes Mylar screw/POGO cover) L14780-001
(13) Left USB board (includes rubber, Mylar screw/POGO cover, bottom thermal Mylar, side thermal
Mylar, and thermal grease)
L14764-001
(14) Mylar shielding foil kit (for use only in models with a WWAN module) L14793-001
(15) Infrared camera LED board (includes sponge and Mylar screw/POGO cover) L14756-001
(16) Battery connector bracket L14782-001
(17) USB Type-C bracket, right (includes Mylar screw/POGO cover) L14781-001
(18) Right USB board (includes rubber, Mylar screw/POGO cover, bottom thermal Mylar, side thermal
Mylar, and thermal grease)
L14763-001
22 Chapter 3 Illustrated parts catalog
