Right USB board
Description Spare part number
Right USB board (includes rubber, Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar,
and thermal grease)
L14763-001
Right USB board cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and
thermal grease)
L14765-001
Right USB board bracket (includes Mylar screw/POGO cover) L14781-001
Before removing the right USB board, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display assembly on page 32).
5. Remove the Mylar shield (see Mylar shield (WWAN models only) on page 37).
6. Disconnect the battery (see Battery on page 40).
7. Remove the audio board (see Battery on page 40).
Remove the right USB board:
1. Disconnect the cable from the board (1).
2. Remove the Phillips M2.0×2.0 screw (2) that secures the board to the tablet.
58 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
