HP ENVY x2 12

Cable identication
Description Spare part number
Audio jack cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and
thermal grease)
L14769-001
Right USB board cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and
thermal grease)
L14765-001
Display (LVDS) cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and
thermal grease)
L14775-001
POGO (keyboard) pin connector cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side
thermal Mylar, and thermal grease)
L14776-001
Left USB board cable (includes Mylar screw/POGO cover, bottom thermal Mylar, side thermal Mylar, and
thermal grease)
L14766-001
Identify the main cables:
▲
Use the following illustration to identify the main cables in the tablet:
(1): Audio jack cable
(2): USB Type-C cable, right
(3): Display (LVDS) cable
(4): POGO (keyboard) cable
(5): USB Type-C cable, left
54 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
