Cameras
Description Spare part number
Infrared camera (include Mylar screw/POGO cover) L14772-001
Front-facing camera (include Mylar screw/POGO cover) L14773-001
Rear-facing camera (include Mylar screw/POGO cover) L14774-001
Before removing the cameras, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display assembly on page 32).
5. Remove the Mylar shield (see Mylar shield (WWAN models only) on page 37).
6. Disconnect the battery cable from the system board (see Battery on page 40).
Remove the infrared camera:
1. Use the following image to identify the cameras:
(1): Infrared camera
(2): Front-facing camera
(3): Rear-facing camera
Component replacement procedures 47
