WLAN antennas
Description Spare part number
WLAN Antenna Kit (includes main and aux antennas and cables, Mylar screw/POGO cover, thermal shield
bottom Mylar, thermal shield side Mylar (2), and thermal grease)
L14787-001
Before removing the WLAN antenna, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display assembly on page 32), and then remove the following
components:
a. Mylar shield (see Mylar shield (WWAN models only) on page 37)
b. Battery (see Battery on page 40)
c. Thermal solution (see Thermal solution on page 38)
d. Solid-state drive (see Solid-state drive on page 42)
e. WWAN module (if applicable) (see WWAN module (select models only) on page 44)
f. System board (see System board on page 61)
Remove the WLAN antenna:
1. Left WLAN antenna; models without a WWAN module:
Remove the left WLAN antenna from the left speaker:
a. Disconnect the antenna cable from the WLAN module (1).
b. Peel the antenna o the speaker (2)
c. Remove the cable from the routing path on top of the speaker (3)
Component replacement procedures 65
