Component Spare part number
Pen tip, Cadillac L04536-001
Pen tip, Impreza L04536-002
Hub, USB Type-C to USB Type-A 916838-001
Hub, USB Type-C to Multi Port Hub 919666-001
SD card tray L14779-001
SIM card tray L14790-001
Brackets
Volume button board bracket (includes Mylar screw/POGO cover) L14761-001
USB Type-C bracket, left (includes Mylar screw/POGO cover) L14780-001
USB Type-C bracket, right (includes Mylar screw/POGO cover) L14781-001
Battery connector bracket L14782-001
Solid-state drive shielding cover (includes WLAN RF foil and Mylar screw/POGO cover) L14755-001
Touch cable tape kit (includes tape for both ends of the touch cable) L20774-001
WWAN/SSD part kit (for use only in models with a WWAN module; includes SSD top absorber, SSD
shielding, WWAN left foil gasket, and WWAN left gasket)
L21710-001
Touch control board foil (for use only in models with a WWAN module) L20775-001
Mylar shielding foil kit (for use only in models with a WWAN module) L14793-001
Display panel connector foil kit (for use only in models with a WWAN module; includes display panel
connector foil and Mylar screw/POGO cover)
L14794-001
Display panel gasket kit (for use only in models with a WWAN module; includes 21 mm gasket, 243 mm
gasket, and Mylar screw/POGO cover)
L14796-001
WWAN connector gasket (for use only in models with a WWAN module; includes WWAN connector
gasket and Mylar screw/POGO cover)
L14792-001
System board gasket kit (for use only in models with a WWAN module) L14795-001
Screw Kit L14800-001
26 Chapter 3 Illustrated parts catalog
