Configuration in UEFI System UtilitiesConfiguration in UEFI System Utilities
This section contains information about using the Smart Array Configuration utility within the UEFI System Utilities to manage the controller.
For more information about the options mentioned in this section, see other sections in this guide and HPE MR Storage Administrator User GuideHPE MR Storage Administrator User Guide.
SubtopicsSubtopics
Viewing controller information and performing common actionsViewing controller information and performing common actions
Configuration managementConfiguration management
Controller managementController management
Advanced controller managementAdvanced controller management
Configuring advanced controller propertiesConfiguring advanced controller properties
Logical drive managementLogical drive management
Drive managementDrive management
Viewing controller information and performing common actionsViewing controller information and performing common actions
About this taskAbout this task
Use the Dashboard View screen to view the properties of the controller, view the server profile, and perform common actions.
ProcedureProcedure
1. From the System Utilities screen, select System Configuration > HPE MRXXX Gen11.
2. In the Dashboard View panel, click Main Menu to access the main menu.
3. Click Help to view the help content.
4. View the properties.
SettingSetting DefinitionDefinition
Status Status of the controller.
Backplane Number of backplanes connected to the controller.
Enclosure Number of enclosures connected to the controller.
Drives Number of drives connected to the controller.
Arrays Number of arrays on the controller.
Logical Drives Number of logical drives on the controller.
ROC
Temperature
(C)
The temperature of the ROC.
View Server
Profile
Shows the UEFI spec version that this system supports and menu options such as Controller Management, Hardware Components, Drive
Management, and Logical Drive Management.
5. Perform the common actions, as needed:
Configuration management
Setting factory defaults
6. View any background operations in progress.
7. View the status of the advanced software options.
NOTE:NOTE:
In this version of the controller, all advanced software options are enabled.
8. Optional. Click Manage MegaRAID Advanced Software Options to view the list of activated advanced software options.
Configuration managementConfiguration management
HPE MR Gen11 Controller User Guide 33
