Installing and Configuring the ACL Tape Drive for the
NonStop NS-Series Server
M8501 and M8502 ACL Tape Drive Installation and User’s Guide—529972-001
3-2
Overview
Figure 3-1. Hardware Configuration
Tape Drive
Fiber
Cable
FCSA
NonStop
NS-Series
Server
