ItemItem DescriptionDescription
1 Media bay
2 2 SFF hot-plug drive cage (optional)
3 Optical drive (optional)
4 Serial number/iLO information pull tab
5 iLO service port
6 USB 3.2 Gen1 port
7 4 SFF hot-plug drives
The media bay supports the optical drive cage or the 2 SFF drive cage option.
The 2 SFF drive cage supports SAS, SATA, or U.3 NVMe drives.
The serial number/iLO information pull tab is double-sided. One side shows the server serial number and the customer asset tag label.
The other side shows the default iLO account information.
The 4 SFF drive bays support SAS or SATA drives.
1
2
3
4
1
2
3
4
