3. Detach the touchpad cable (3) from the computer. The cable is attached with double-sided
adhesive.
To replace the touchpad cable, reverse the removal procedures.
NFC module antenna
To remove the NFC module antenna, use this procedure and illustration.
NOTE: The NFC module antenna is included with the touchpad spare part kit with spare part number
N50690-001.
Before removing the NFC module antenna, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 41).
2. Remove the service cover (see Service cover on page 41).
3. Remove the battery (see Battery on page 42).
Remove the NFC module antenna:
1. Disconnect the NFC module antenna (1) from the NFC module.
56
Chapter 6 Removal and replacement procedures for authorized service provider parts
