HPE ProLiant DL360 Gen11 - Results; Removing and replacing the EDSFF drive backplane; Procedure

2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
a. Extend the server from the rack .
b. Remove the server from the rack .
4. Remove the access panel .
5. Remove all drives and drive blanks.
Note where each drive is located.
6. If installed, remove the Smart Storage Battery .
7. Disconnect all cables from the drive backplane.
8. Remove the drive backplane.
ResultsResults
To replace the component, reverse the removal procedure.
Removing and replacing the EDSFF drive backplaneRemoving and replacing the EDSFF drive backplane
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
HPE ProLiant DL360 Gen11 Server Maintenance and Service Guide 109
