9. Using an alcohol wipe, remove the existing thermal grease.
Allow solvent to dry before making contact with thermal grease.
10. Align the latches and pin 1 indicator, and then install the frame to the heatsink.
Verify that all of the latches are engaged with the heatsink.
11.
Install the processor heatsink assembly.
The installation is complete.
Installing a processor
Observe the following:
• Before performing this procedure, HPE recommends identifying the
processor, heatsink, and socket components.
• Intelligent System Tuning supports specific processors and configurations. For more information, see the product
QuickSpecs on the
HPE website.
IMPORTANT: Existing HPE ProLiant and HPE Synergy Gen10 server products containing first-generation Intel Xeon
Scalable processors may not be upgraded to second-generation Intel Xeon Scalable processors at this time.
For more information, see the product QuickSpecs on the Hewlett Packard Enterprise website (
https://www.hpe.com/
info/qs).
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• The components included with the hardware option kit
• T-30 Torx screwdriver
Procedure
1. Observe the following alerts.
Hardware options installation
148
