HPE ProLiant DL380 Gen10 - Removing the Hard Drive Blank; Accessing the Systems Insight Display

Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
•
Extend the server from the rack.
• Remove the server from the rack.
4. Remove the access panel.
5.
Remove the riser cage.
6. Remove the blank.
Removing the hard drive blank
Remove the component as indicated.
Accessing the Systems Insight Display
The Systems Insight Display is supported only on SFF models.
Procedure
1. Press and release the panel.
2. After the display fully ejects, rotate the display to view the LEDs.
Operations
57
