Removal and replacement procedures 49
9.
Remove the processor from the processor retaining bracket.
To replace the component:
1. Install the processor. Verify that the processor is fully seated in the processor retaining bracket by
visually inspecting the processor installation guides on either side of the processor. THE PINS ON
THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED.
THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY
DAMAGED. To avoid damage to the system board, do not touch the processor or the
processor socket contacts.
CAUTION: Do not press down on the processor. Pressing down on the processor might
damage the processor socket and the system board. Press only in the area indicated on the
processor retaining bracket.
