Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―120― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
d00.11
Master setting
frequency source
0－4 *
d00.12
Master setting
frequency
0.01－400.00Hz *
d00.13
Auxiliary setting
frequency
0.01－400.00Hz *
d00.14 Setting frequency 0.01－400.00Hz *
d00.15
Reference frequency
(after acceleration/
deceleration)
0.01－400.00Hz *
d00.16 Output frequency 0.01－400.00Hz *
d00.17 Setting speed 0－60000rpm *
d00.18 Running speed 0－60000rpm *
d00.19
Three-phase power
supply input sequence
phase
0: Positive sequence, L1(R)
preceding L2(S) preceding
L3(T)
1: Negative sequence, L1(R)
preceding L3(T) preceding
L2(S)
*
d00.20 Output voltage 0－999V *
d00.21 Output current 0.1A *
d00.22 Reserved
d00.23 Output torque
0－300.0% (motor rated
torque)
*
d00.24 Output power
0－200% (motor rated
power)
*
d00.25 DC bus voltage 0－999V *
d00.26
Potentiometer input
voltage of the display
panel
0.00－5.00V *
d00.27 AI1 input voltage 0.00－10.00V *
d00.28
AI1 input voltage (after
disposal)
0.00－10.00V
*
d00.29 AI2 input voltage -10.00－10.00V *
d00.30
AI2 input voltage (after
disposal)
-10.00－10.00V *
d00.31 AI3 input voltage -10.00－10.00V *
d00.32
AI3 input voltage (after
disposal)
-10.00－10.00V *
d00.33 AI4 input voltage -10.00－10.00V *
d00.34
AI4 input voltage (after
disposal)
-10.00－10.00V
*
d00.35
DI6 terminal pulse
input frequency
0－50000Hz *
