Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －121－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
d00.36 AO1 output 0.00－10.00V *
d00.37 AO2 output 0.00－10.00V *
d00.38
High-speed output
pulse frequency
0－50000Hz *
d00.39 Heatsink temperature 0.0－999.9℃ *
d00.40 Reserved
d00.41 Reserved
d00.42 Reserved
d00.43 Reserved
d00.44 Process PID reference -100.0－100.0% *
d00.45 Process PID feedback -100.0－100.0% *
d00.46 Process PID tolerance -100.0－100.0% *
d00.47
Process PID integral
item
-100.0－100.0% *
d00.48 Process PID output -100.0－100.0% *
d00.49 External counting value 0－9999 *
d00.50 Input terminal status
Bit0－Bit8 corresponding to
DI1－DI9
Bitx: DIy terminals input
positive and negative logic
0: Positive logic
1: Negative logic
Only using HD30-EIO and
HD30-WIO can the DI7－DI9
be enabled.
*
d00.51 Output terminal status
Bit0－Bit1 corresponding to
DO1－DO2
Bit2－Bit11 corresponding to
RLY1－RLY10
Bitx: DOy, RLYy terminals
output positive and negative
logic
0: Positive logic
1: Negative logic
Only with the corresponding
extension options can the
RLY2－RLY10 be enabled.
With HD30-EIO, RLY2－
RLY4 are enabled; With
HD30-WIO, RLY2－RLY10
are enabled
*
d00.52
MODBUS
communication status
0: Normal
1: Communication timeout
2: Incorrect data frame head
3: Incorrect data frame
*
A
