Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －123－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
applications
F00.06
Inverter max. output
frequency
50.00－400.00Hz 50.00Hz 0.01Hz ×
F00.07
Upper limit of operation
frequency setting
source
0: Digital setting (F00.08)
1: Analogue input AI setting
2: Terminal pulse setting
0 1 ×
F00.08
Upper limit of operation
frequency
0.00－F00.06 50.00Hz 0.01Hz ×
F00.09
Lower limit of operation
frequency
0.00－upper limit 0.00Hz 0.01Hz ×
F00.10
Frequency setting
sources selection
0: Display panel digital
setting
1: Terminal digital setting
2: SCI communication setting
3: AI analogue setting
4: Terminal pulse setting
0 1 ×
F00.11
Command setting
source selection
0: Display panel running
source
1: Terminal running source
2: SCI communication
running source
0 1 ×
F00.12
Function selection of
the multi-function key
0: Switch the display panel
running direction
1: Switch local and remote
control
0 1 ○
F00.13
Starting frequency
digital setting
0.00－upper limit 50.00Hz 0.01Hz ○
F00.14
UP/DOWN digital
setting control
Units: Frequency setting
save selection at power
outage
0: Frequency setting will not
be saved at power outage
1: Frequency setting will be
saved to F00.13 at power
outage
Tens: Frequency setting
control selection at stop
0: Frequency setting will not
be restored to F00.13 at stop
1: Frequency setting will be
restored to F00.13 at stop
00 1 ×
F00.15
Jog operation
frequency digital
setting 1
0.00－upper limit 5.00Hz 0.01Hz ○
F00.16 Interval of jog operation 0.0－100.0s 0.0s 0.1s ×
