Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －125－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F02.02
Start DWELL
frequency setting
0.00－upper limit 0.00Hz 0.01Hz ×
F02.03
Retention time of
starting DWELL
frequency
0.00－10.00s 0.00s 0.01s ×
F02.04
DC braking current
setting
0－100% (inverter’s rated
current)
50% 1% ×
F02.05
DC braking time at
start
0.00－10.00s 0.50s 0.01s ×
F02.06
Speed tracking mode
selection
0: Searching based on
residual voltage
1: Searching based on
current
0 1 ×
F02.07
Speed search mode
based on current
0: From the max. output
frequency to start speed
searching
1: From the stopping
frequency to start speed
searching
1 1 ×
F02.08
Setting reference
current for speed
search
0－100% (motor’s rated
current)
50% 1% ×
F02.09
Acc./Dec. time of the
speed search
1.0－50.0s 5.0s 0.1s ×
F02.10
Waiting time of speed
search
0.1－5.0s 1.0s 0.1s ×
F02.11
V/f ratio of speed
search
0.0－100.0% 100.0% 0.1% ×
F02.12
Disposal time after
speed search
0.01－5.00s 1.00s 0.01s ×
F02.13 Stop mode selection
0: Decelerate to stop
(decreases to DWELL
frequency setting and holds
on retention time of DWELL
frequency, then it will stop)
1: Coast to stop
2: Decelerate to stop with DC
braking
0 1 ×
F02.14
DWELL frequency
setting at stop
0.00－upper limit 0.00Hz 0.01Hz ×
F02.15
Retention time of
DWELL frequency at
stop
0.00－10.00s 0.00s 0.01s ×
F02.16
DC braking initial
frequency at stop
0.00－50.00Hz 0.50Hz 0.01Hz ×
F02.17
DC braking waiting
0.00－10.00s 0.50s 0.01s ×
A
