Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―126― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
time at stop
F02.18 DC braking time at stop 0.00－10.00s 0.50s 0.01s ×
Group F03 Acceleration/Deceleration Parameters (refer to pages 62
－
63)
F03.00
Acc./Dec. mode
selection
0: Linear Acc. or Dec.
1: S-curve Acc. or Dec.
0 1 ○
F03.01 Acceleration time 1 0.1－6000.0s 15kW or
below
models:
10.0s
18.5－55
Kw: 20.0s
other
models:
30.0s
0.1s ○
F03.02 Deceleration time 1 0.1－6000.0s 0.1s ○
F03.03 Acceleration time 2 0.1－6000.0s 0.1s ○
F03.04 Deceleration time 2 0.1－6000.0s 0.1s ○
F03.05 Acceleration time 3 0.1－6000.0s 0.1s ○
F03.06 Deceleration time 3 0.1－6000.0s 0.1s ○
F03.07 Acceleration time 4 0.1－6000.0s 0.1s ○
F03.08 Deceleration time 4 0.1－6000.0s 0.1s ○
F03.09
Switching frequency of
acceleration time 2 and
time 1
0.00－upper limit 0.00Hz 0.01Hz ×
F03.10
Switching frequency of
deceleration time 2 and
time 1
0.00－upper limit 0.00Hz 0.01Hz ×
F03.11
S-curve characteristic
time at starting
acceleration
0.00－2.50s 0.20s 0.01s ○
F03.12
S-curve characteristic
time at ending
acceleration
0.00－2.50s 0.20s 0.01s ○
F03.13
S-curve characteristic
time at starting
deceleration
0.00－2.50s 0.20s 0.01s ○
F03.14
S-curve characteristic
time at ending
deceleration
0.00－2.50s 0.20s 0.01s ○
F03.15
Acceleration time of jog
operation
0.1－6000.0s 6.0s 0.1s ○
F03.16
Deceleration time of
jog operation
0.1－6000.0s 6.0s 0.1s ○
F03.17
Deceleration time of
emergency stop
0.1－6000.0s 10.0s 0.1s ○
Group F04 Process PID Control (refer to pages 63
－
65)
F04.00
Process PID control
selection
0: PID control is disabled
1: PID control is enabled
0 1 ×
F04.01
Reference source
selection
0: Digital reference
1: AI analogue reference
2: Terminal pulse reference
0 1 ×
