Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －127－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F04.02
Feedback source
selection
0: AI analogue feedback
1: Terminal pulse feedback
0 1 ×
F04.03
Setting digital
reference
-10.00－10.00V 0.00V 0.01V ○
F04.04 Proportional gain (P) 0.00－10.00 2.00 0.01 ○
F04.05 Integral time (I) 0.00－10.00s 1.00s 0.01s ○
F04.06 Integral upper limit 0.00－upper limit 50.00Hz 0.01Hz ○
F04.07 Differential time (D)
0.00－10.00s
The differential is disabled
when F04.07 is set to 0
0.00s 0.01s ○
F04.08
Differential amplitude
limit value
0.00－upper limit 20.00Hz 0.01Hz ○
F04.09 Sampling cycle (T) 0.01－50.00s 0.10s 0.01s ○
F04.10 Bias limit 0.0－20.0% (reference) 2.0% 0.1% ○
F04.11
PID regulator upper
limit source selection
0: Set by F04.13
1: Set by AI analogue value
2: Set by terminal pulse input
0 1 ×
F04.12
PID regulator lower
limit source selection
0: Set by F04.14
1: Set by AI analogue value
2: Set by terminal pulse input
0 1 ×
F04.13
PID regulator upper
limit value
0.00－upper limit 50.00Hz 0.01Hz ×
F04.14
PID regulator lower
limit value
0.00－upper limit 0.00Hz 0.01Hz ×
F04.15
PID regulator
characteristic
0: Positive
1: Negative
0 1 ×
F04.16
Integral regulation
selection
0: Stop integral regulation
when the frequency reaches
the upper or lower limit
1: Continue the integral
regulation when the
frequency reaches the upper
or lower limit
0 1 ×
F04.17 PID output filter time 0.01－10.00s 0.05s 0.01s ○
F04.18
PID output reverse
selection
0: PID regulation disable
reverse (When PID output is
negative, 0 is the limit)
1: PID regulation enable
reverse (When F00.18 = 1
disable reverse, 0 is the limit)
0
×
F04.19
PID output reverse
frequency’s upper limit
0.00Hz－upper limit 50.00Hz 0.01Hz ×
Group F05 External Reference Curve Parameters (refer to pages 65
67)
F05.00
External reference
curve selection
Units: AI1 characteristic
curve selection
00000 1 ×
A
