Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―128― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
Tens: AI2 characteristic
curve selection
Hundreds: AI3 characteristic
curve selection
Thousands: AI4
characteristic curve selection
Ten thousands: Pulse input
characteristic curve selection
0: Line 1
1: Line 2
2: Polyline
Only when using HD30-EIO
can hundreds and thousands
be enabled.
F05.01
Minimum reference of
line 1
0.0－F05.03 0.0% 0.1% ○
F05.02
Minimum reference
corresponding value of
line 1
0.0－100.0% 0.0% 0.1% ○
F05.03
Maximum reference of
line 1
F05.01－100.0% 100.0% 0.1% ○
F05.04
Maximum reference
corresponding value of
line 1
0.0－100.0% 100.0% 0.1% ○
F05.05
Minimum reference of
line 2
0.0－F05.07 0.0% 0.1% ○
F05.06
Minimum reference
corresponding value of
line 2
0.0－100.0% 0.0% 0.1% ○
F05.07
Maximum reference of
line 2
F05.05－100.0% 100.0% 0.1% ○
F05.08
Maximum reference
corresponding value of
line 2
0.0－100.0% 100.0% 0.1% ○
F05.09
Maximum reference of
polyline
F05.11－100.0% 100.0% 0.1% ○
F05.10
Maximum reference
corresponding value of
polyline
0.0－100.0% 100.0% 0.1% ○
F05.11
Inflection point 2
reference of polyline
F05.13－F05.09 100.0% 0.1% ○
F05.12
Inflection point 2
corresponding value
0.0－100.0% 100.0% 0.1% ○
F05.13
Inflection point 1
reference of polyline
F05.15－F05.11 0.0% 0.1% ○
F05.14
Inflection point 1
0.0－100.0% 0.0% 0.1% ○
