Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －129－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
corresponding value
F05.15
Minimum reference of
polyline
0.0－F05.13 0.0% 0.1% ○
F05.16
Minimum reference
corresponding value of
polyline
0.0－100.0% 0.0% 0.1% ○
F05.17 Skip frequency 1 F00.09－upper limit 0.00Hz 0.01Hz ×
F05.18 Skip frequency 2 F00.09－upper limit 0.00Hz 0.01Hz ×
F05.19 Skip frequency 3 F00.09－upper limit 0.00Hz 0.01Hz ×
F05.20
Range of skip
frequency
0.00－30.00Hz 0.00Hz 0.01Hz ×
F05.21
Jog operation
frequency digital
setting 2
0.00－upper limit 5.00Hz 0.01Hz ○
Group F06 MS SPEED and Simple PLC (refer to pages 67
－
71)
F06.00
Multi-step frequency
command 1
F00.09－upper limit 3.00Hz 0.01Hz ○
F06.01
Multi-step frequency
command 2
F00.09－upper limit 6.00Hz 0.01Hz ○
F06.02
Multi-step frequency
command 3
F00.09－upper limit 9.00Hz 0.01Hz ○
F06.03
Multi-step frequency
command 4
F00.09－upper limit 12.00Hz 0.01Hz ○
F06.04
Multi-step frequency
command 5
F00.09－upper limit 15.00Hz 0.01Hz ○
F06.05
Multi-step frequency
command 6
F00.09－upper limit 18.00Hz 0.01Hz ○
F06.06
Multi-step frequency
command 7
F00.09－upper limit 21.00Hz 0.01Hz ○
F06.07
Multi-step frequency
command 8
F00.09－upper limit 24.00Hz 0.01Hz ○
F06.08
Multi-step frequency
command 9
F00.09－upper limit 27.00Hz 0.01Hz ○
F06.09
Multi-step frequency
command 10
F00.09－upper limit 30.00Hz 0.01Hz ○
F06.10
Multi-step frequency
command 11
F00.09－upper limit 33.00Hz 0.01Hz ○
F06.11
Multi-step frequency
command 12
F00.09－upper limit 36.00Hz 0.01Hz ○
F06.12
Multi-step frequency
command 13
F00.09－upper limit 39.00Hz 0.01Hz ○
F06.13
Multi-step frequency
command 14
F00.09－upper limit 42.00Hz 0.01Hz ○
F06.14
Multi-step frequency
command 15
F00.09－upper limit 45.00Hz 0.01Hz ○
A
