Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―140― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
setting Bitx: DIy terminal input
positive and negative logic
0: Positive logic
1: Negative logic
Only when using HD30-EIO
and HD30-WIO will DI7－DI9
be enabled.
F15.16
FWD/REV operation
mode
0: Two-wire operation mode
1
1: Two-wire operation mode
2
2: Three-wire operation
mode 1
3: Three-wire operation
mode 2
0 1 ×
F15.17
Terminal operating
selection due to fault of
external equipment
0: Coast to stop
1: Emergency stop
2: Decelerate to stop
3: Continue to run
0 1 ×
F15.18
DO1 terminal function
selection
0: Reserved
1: Inverter ready
2: Inverter is running (RUN)
3: Inverter is forward running
4: Inverter is reverse running
5: Inverter is DC braking
6: Inverter is in
zero-frequency status
7: Inverter is in
zero-frequency running
8: Reserved
9,10: Frequency detection
threshold (FDT1,FDT2)
11: Frequency arriving signal
(FAR)
12: Limitation of upper limit of
frequency
13: Limitation of lower limit of
frequency
14: Limitation of upper/lower
limits of wobble frequency
15: Simple PLC operating
status indication
16: Simple PLC pausing
indication
0 1 ×
F15.19
DO2 terminal function
selection
0 1 ×
F15.20
RLY1 relay function
selection
31 1 ×
F15.21
RLY2 relay (extension
relay) function
selection
0 1 ×
To Next Page
