Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －141－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.22
RLY3 relay (extension
relay) function
selection
17: Simple PLC cycle
completion indication
18: Completion of simple
PLC operation stages
19: Completion of simple
PLC operation
20: Output data from SCI
communication
21: Preset operating time out
22: Timing function output
23: Preset counting value
reach
24: Indicating counting value
reach
25: Setting length arrive
26: Indication of motor 1 and
motor 2
27,28: Reserved
29: Undervoltage lock-up
signal (LU)
30: Overload signal (OL)
31: Inverter fault
32: External fault
33: Inverter auto-reset fault
34: Three-phase power
supply forward input
35－37：Reserved
38: High-frequency output
(only DO2)
0 1 ×
F15.23
RLY4 relay (extension
relay) function
selection
0 1 ×
F15.24
Output terminal
positive and negative
logic selection
Bit0－Bit2 is corresponding
to DO1－DO2
Bit2－Bit5 is corresponding
to RLY1－RLY4
Bitx: DOy and RLYy
terminals output positive and
negative logic
0 means positive logic
1 means negative logic
Only when using HD30-EIO
will RLY2－RLY4 be
enabled.
00 1 ○
F15.25
ON side delay time of
timing function
0.00－300.00s 0.00s 0.01s ○
F15.26
OFF side delay time of
timing function
0.00－300.00s 0.00s 0.01s ○
F15.27 FAR range 0.00－100.00Hz 2.50Hz 0.01Hz ○
A
