Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―142― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.28
Zero-frequency
operation threshold
0.00－F00.06 0.00Hz 0.01Hz ○
F15.29
Zero-frequency
hysteresis
0.00－F00.06 0.00Hz 0.01Hz ○
F15.30 FDT1 detection mode
0: Detect according to the
reference frequency
1: Detect according to the
output frequency
0 1 ○
F15.31 FDT1 level 0.00－F00.06 50.00Hz 0.01Hz ○
F15.32 FDT1 lag 0.00－F00.06 1.00Hz 0.01Hz ○
F15.33 FDT2 detection mode
0: Detect according to the
reference frequency
1: Detect according to the
output frequency
0 1 ○
F15.34 FDT2 level 0.00－F00.06 50.00Hz 0.01Hz ○
F15.35 FDT2 lag 0.00－F00.06 1.00Hz 0.01Hz ○
F15.36 Preset operating time
0－65535h
0: Preset operating time is
disabled
0h 1h ○
F15.37
Preset counting value
arriving
F15.38－9999 0 1 ○
F15.38
Specified counting
value arriving
0－F15.37 0 1 ○
F15.39 Reserved
F15.40 Reserved
F15.41 Reserved
F15.42 Reserved
Group F16 Analogue I/O Terminal Parameters (refer to pages 92
－
96)
F16.00
Display panel with
potentiometer function
selection
0: Reserved
1: Upper limit frequency
setting source
2: Frequency setting source
3: Auxiliary frequency
reference
4: Process PID reference
5: Process PID feedback
6: Process PID regulating
upper limit
7: Process PID regulating
lower limit
8: Motor overheating signal
input
0 1 ×
F16.01
Analogue input AI1
function selection
0 1 ×
F16.02
Analogue input AI2
function selection
0 1 ×
F16.03
Analogue input AI3
function selection
0 1 ×
F16.04
Analogue input AI4
function selection
0 1 ×
F16.05
Analogue input AI1
bias
-100.0－100.0% 0.0% 0.1% ○
F16.08
Analogue input AI2
-100.0－100.0% 0.0% 0.1% ○
