hpmont HD30 Series Manual

Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －143－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
bias
F16.11
Analogue input AI3
bias
-100.0－100.0% 0.0% 0.1% ○
F16.14
Analogue input AI4
bias
-100.0－100.0% 0.0% 0.1% ○
F16.06
Analogue input AI1
gain
-10.0－10.0 1.0 0.1 ○
F16.09
Analogue input AI2
gain
-10.0－10.0 1.0 0.1 ○
F16.12
Analogue input AI3
gain
-10.0－10.0 1.0 0.1 ○
F16.15
Analogue input AI4
gain
-10.0－10.0 1.0 0.1 ○
F16.07
Analogue input AI1
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.10
Analogue input AI2
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.13
Analogue input AI3
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.16
Analogue input AI4
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.17
Maximum input pulse
frequency
0.0－50.0kHz 10.0kHz 0.1kHz ○
F16.18
Input pulse filtering
time
0－500ms 10ms 1ms ○
F16.19
AO1 terminal output
function selection
0: Reserved
1: Output frequency (0－
max. output frequency)
2: Reference frquency (0－
max. output frequency)
3: Motor speed (0－
maximum output frequency
corresponding to speed)
4: Output current (0－twice
motor’s rated current)
5: Output current (0－twice
motor’s rated current)
6－9: Reserved
10: Output torque (0－3
0 1 ○
F16.20
AO2 terminal output
function selection
0 1 ○
