Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―144― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F16.21
High-speed pulse
output function
selection
times motor’s rated torque)
11: Output voltage (0－1.2
times inverter’s rated
voltage)
12: Bus voltage (0－2.2
times inverter’s rated
voltage)
13: Output power (0－twice
motor’s rated power)
14: AI1 input (0－10V)
15: AI2 input (-10－10V / 0－
20mA)
16: AI3 input (-10－10V / 0－
20mA)
17: AI4 input (-10－10V / 0－
20mA)
18: Output frequency (- 1
times－1 times maximum
output frequency)
19: Reference frequency (- 1
times－1 times maximum
output frequency)
0 1 ○
F16.22
Analogue output AO1
bias
-100.0－100.0% 0.0% 0.1% ○
F16.23
Analogue output AO1
gain
0.0－200.0% 100.0% 0.1% ○
F16.24
Analogue output AO2
bias
-100.0－100.0% 0.0% 0.1% ○
F16.25
Analogue output AO2
gain
0.0－200.0% 100.0% 0.1% ○
F16.26
DO2 maximum output
pulse frequency
0.0－50.0kHz 10.0kHz 0.1kHz ○
Group F17 SCI Communication Parameters (refer to pages 96
－
97)
F17.00 Data format
0: 1-8-2 format, no parity,
RTU
1: 1-8-1 format, even
parity,RTU
2: 1-8-1 format, odd parity,
RTU
3: 1-7-2 format, no parity,
ASCII
4: 1-7-1 format, even parity,
ASCII
5: 1-7-1 format, odd parity,
ASCII
0 1 ×
F17.01 Baud rate selection
0: 1200bps
1: 2400bps
3 1 ×
